Next-Gen Wi-Fi 7: Harness the power of the latest Wi-Fi standard—Utilize the 6 GHz band, 320 MHz channels, 4K-QAM, MLO and Multi-RU across 6 streams for optimized signal distribution throughout your entire home.
Unrivaled 10.8 Gbps Wi-Fi Speeds: Tri-band Wi-Fi with dedicated 6 GHz (5764 Mbps), 5 GHz (4323 Mbps), and 2.4 GHz (688 Mbps) bands delivers ultimate speed, reduced congestion, and seamless connectivity for every device.†
6 GHz Band: The newest 6 GHz band offers more channels and a wider spectrum, minimizing interference and congestion from neighboring networks and older devices.△
Multi-Link Operation (MLO): Experience significant gains in data transfer speeds, response times, and network stability for future-proof connectivity.△
2.5G Multi-Gigabit Ethernet Port: Smoother streaming, faster downloads, and lower latency for all your connected devices while effortlessly handling bandwidth demands of today's most demanding applications.
Smart Adaptive Roaming: Walk from room to room while automatically connecting to the most optimal node—Experience strong signals and continuous connections even as you roam.§
Works with EasyMesh: EasyMesh compatibility offers flexible expansion and unbeatable whole-home coverage by simply connecting the RE655BE to an EasyMesh compatible router or mesh system.
Easy Setup: Plug in and then easily set up via a press of the WPS button or via the Tether App.
Great Compatibility: Works with all Wi-Fi generations and devices and all internet providers
Interface
1× 2.5 Gbps LAN Port
Button
• WPS Button
• Reset Button
Input Power
100-240V~50/60Hz 0.5A
Max. Power Consumption
23.5W
Dimensions (W x D x H)
107.2 × 39 × 161 mm
Antenna
4 External Antennas
WIRELESS FEATURES
Wireless Standards
Wi-Fi 7
IEEE 802.11be/ax 6 GHz
IEEE 802.11be/ax/ac/n/a 5 GHz
IEEE 802.11be/ax/n/b/g 2.4 GHz
Frequency
• 6 GHz
• 5 GHz
• 2.4 GHz
Signal Rate
• 5764 Mbps at 6 GHz
• 4323 Mbps at 5 GHz
• 688 Mbps at 2.4 GHz
Working Modes
Range Extender/Access Point
Reception Sensitivity
6GHz:
11be HE20 MCS0：-95dBm, 11be HE20 MCS13：-60dBm
11be HE40 MCS0：-92dBm, 11be HE40 MCS13：-57dBm
11be HE80 MCS0：-88dBm, 11be HE80 MCS13：-53dBm
11be HE160 MCS0：-85dBm, 11be HE160 MCS13：-50dBm
11be HE320 MCS0：-81dBm, 11be HE160 MCS13：-46dBm
5GHz:
11be HE20 MCS0：-93dBm, 11be HE20 MCS13：-58dBm
11be HE40 MCS0：-89dBm, 11be HE40 MCS13：-54dBm
11be HE80 MCS0：-87dBm, 11be HE80 MCS13：-51dBm
11be HE160 MCS0：-85dBm, 11be HE160 MCS13：-49dBm
11be HE240 MCS0：-83dBm, 11be HE160 MCS13：-47dBm
2.4GHz:
11be HE20 MCS0：-97dBm, 11be HE20 MCS11：-64dBm
11be HE40 MCS0：-95dBm, 11be HE40 MCS11：-62dBm
Wireless Security
• WPA/WPA2-PSK encryptions
• WPA3
Advanced Features • Multi-Link Operation (MLO)
• 320 MHz Channel
• 4K-QAM
• Multi-RUs
Transmission Power FCC:
• 2.4GHz < 30dBm
• 5GHz < 30dBm
• 6GHz < 30dBm
Mesh Technology
EasyMesh-Compatible
Wireless Function
• LED Control
• Access Control
• Power Schedule
• Wi-Fi Coverage
OTHERS
Certification FCC, RoHS
Package Content
• Wi-Fi 7 Range Extender RE655BE
• Quick Installation Guide
System Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or
Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari
4.0, or other Java-enabled browser
Environment
• Operating Temperature: 0℃~40℃ (32℉ ~104℉)
• Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
