POWER
AC adapter input 100-240V ~ 50/60Hz 0.4A
AC adapter output 12V ? 1.2A
HARDWARE FEATURES
Processor Quad-core CPU
Interface 2 LAN/WAN Gigabit Ethernet Ports
Button 1 Reset button on the underside
External Power Supply 12 V/1.2 A
Dimensions Φ4.7 in. x 1.5 in. (Φ120 mm x 38 mm)
Antenna 4 internal antennas per Deco unit
Bluetooth version 4.2 and above
WIRELESS FEATURES
Wireless Standards IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
Frequency 2.4 GHz and 5 GHz
Signal Rate 400 Mbps on 2.4 GHz
867 Mbps on 5 GHz
Transmit Power FCC: <30 dBm
CE: <20 dBm (2.4 GHz)
<23 dBm (5 GHz)
Wireless Security WPA-PSK/WPA2-PSK
Advanced Functions ? Router/ Access Point Mode
? Optional Ethernet Backhaul
? TP-Link Mesh Technology:
MU-MIMO
Auto Path Selection
Self-Healing
AP Steering
Band Steering
Beamforming
SOFTWARE FEATURES
Quality of Service WMM
IPv6 Support
WAN Type Dynamic IP/Static IP/PPPoE
Management Local Management, Remote Management
DHCP Server, Client
Port Forwarding Support
Access Control Blacklist
Firewall Security SPI Firewall
Protocols Supports IPv4 and IPv6
Advanced Features Homecare:
Antivirus
Parental Controls
Quality of Service
Advanced Functions Speedtest
Monthly Usage Reports
Auto FW Update
Expand for more deco
Guest Network 2.4 GHz guest network * 1
5 GHz guest network * 1
Beamforming Support
APP Easy setup by Deco App
OTHERS
Certification CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
Package Contents ? Deco M5 (3-pack):
3 Deco units
1 RJ45 Ethernet Cable
3 Power Adapters
? Deco M5 (1-pack):
1 Deco unit
1 RJ45 Ethernet Cable
1 Power Adapter
Smartphone/Tablet Requirements iOS 8.0 or later
Android 4.3 or later
Bluetooth 4.0 or later
Environment Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
