HARDWARE FEATURES
Memory: 1GB RAM and 128MB Flash
Interface:
8 1G/100M/10M LAN Ports,
1 2.5G/2G/1G/100M WAN Port
1 USB-A 3.0 Port + 1 USB-C 3.0 Port
Button: Wi-Fi On/Off Button, Reset Button, WPS Button, Power On/Off Button, LED on/off Button
External Power Supply: 12V/4A
Dimensions ( W x D x H ): 10.3×10.3×2.4in (261.2×261.2×60.2mm)
Antenna: 8 High-Performance External Antennas
WIRELESS FEATURES
Wireless Standards:
IEEE 802.11ax/ac/n/a 5GHz
IEEE 802.11ax/n/b/ 2.4GHz
Frequency: 2.4GHz and 5GHz
Signal Rate:
5GHz: 4804Mbps(802.11ax)
2.4GHz: 1148Mbps(802.11ax)
compatible with 802.11a/b/g/n/ac Wi-Fi standards
Reception Sensitivity
5GHz:
11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm
11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm
11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS11:-55dBm
11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm
11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm
11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm
11ax HE160_MCS0:-85dBm, 11ax HE160_MCS11:-55dBm
2.4GHz:
11g 6Mbps:-97dBm, 11a 54Mbps:-79dBm
11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm
11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm
11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm
11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm
Wireless Functions: Enable/Disable Wireless Radio, Guest network, DFS, MU-MIMIO, OFDMA
Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Transmission Power:
CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.35GHz); <30dBm(5.47GHz~5.725GHz)
FCC: <30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz)
Guest Network: 2.4GHz guest network x 1, 5GHz guest network x 1
SOFTWARE FEATURES
Quality of Service: Advanced Qos powered by TrendMicro
WAN Type: Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access)
Management: Advanced Parental control powered by TrendMicro, Local Management, Remote Management
DHCP: Server, DHCP Client List, Address Reservation
Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, NO-IP, TP-Link
VPN: Server PPTP, OpenVPN
OTHERS
Certification: FCC, CE, RoHS
Package Contents:
Wireless Router Archer AX6000
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
System Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
Environment:
Operating Temperature: 0?~40? (32? ~104?)
Storage Temperature: -40?~70? (-40? ~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
