Next-Gen Gigabit Wi-Fi 6 Speed—2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz band ensure smoother streaming and faster downloads.
Connect More Devices—OFDMA and MU-MIMO technology increase capacity by 4 times to enable simultaneous transmission to more devices.
Ultra-Low Latency—Up to 75% reduction in latency enables more responsive gaming and video chatting.
Expanded Wi-Fi Coverage—Four high-gain external antennas and Beamforming technology combine to extend strong, reliable Wi-Fi throughout your home.
Improved Security—More secure and trusted Wi-Fi with TP-Link HomeCare
Reliable Connections—Intel Home Wi-Fi Chipset greatly increases processing speed to deliver superior Wi-Fi 6 Gig+ performance.
Improved Battery Life—Target Wake Time helps your devices to communicate more while consuming less power.
Compatible with Alexa—Control your router via voice commands and make your life smarter and easier with Amazon Alexa.
HARDWARE FEATURES
Interface:
1 × Gigabit WAN Port,
4 × Gigabit LAN Ports
1 × Tpye A USB 3.0 Port
Button:
WPS/Wi-Fi Button, LED On/Off Button, Power On/Off Button,
Reset Button
External Power Supply 12 V/2 A
Dimensions ( W x D x H ) 10.2 × 5.3 × 1.5 in (260.2 x 135.0 x 38.6 mm)
Antenna 4 × External Antennas
WIRELESS FEATURES
Wireless Standards:
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz
Frequency: 2.4 GHz and 5 GHz
Signal Rate:
5 GHz: 2402 Mbps(802.11ax),
2.4 GHz: 574 Mbps(802.11ax)
compatible with 802.11a/b/g/n/ac Wi-Fi standards
Reception Sensitivity 5 GHz:
11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm
11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm
11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS11:-55dBm
11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm
11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm
11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm
11ax HE160_MCS0:-85dBm, 11ax HE160_MCS11:-55dBm
2.4 GHz:
11g 6Mbps:-97dBm, 11a 54Mbps:-79dBm
11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm
11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm
11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm
11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm
Wireless Functions: Enable/Disable Wireless Radio, WMM, Wireless Statistics
Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Transmission Power
CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.35 GHz); <30dBm(5.47 GHz~5.725 GHz)
FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)
Guest Network 1 × 2.4 GHz Guest Network
1 × 5 GHz Guest Network
SOFTWARE FEATURES
Quality of Service: Device and Application Prioritisation
WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
Management: Access Control, Local Management, Remote Management
DHCP: Server, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, NO-IP, TP-Link
Access Control: Parental Controls, Local Management Control, Host List, White
List, Black List
Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
Protocols: IPv4, IPv6
USB Sharing: Supports Samba(Storage)/FTP Server/Media Server
OTHERS
Package Contents:
Wireless Router Archer AX50
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
System Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
Environment:
Operating Temperature: 0?~40? (32? ~104?)
Storage Temperature: -40?~70? (-40? ~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certifications: CE, FCC, RoHS
