RELIABLE PERFORMANCE
Superior network performance at non-blocking rate delivers true gigabit speed with no compromise
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
PLUG-AND-PLAY
No software to install. No configuration needed. Zero maintenance required
SILENT OPERATION
The fanless design means zero added noise wherever its located, making it ideal for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Install your switch on your desktop, mount it to your wall, or add it to a standard 19 inch (44 mm) rack with the hardware provided in the box
METAL CASE
Durable and rugged case for long-lasting performance
Physical Specification
Dimensions (WxDxH) : 328 x 169 x 43 mm (12.9 x 6.7 x 1.7in)
Weight : 1.47kg (3.24lb)
Technical Specs
Speed : 10/100/1000Mbps Gigibit Ethernet
Number of Ports : 24
PoE ports : n/a
Total PoE Budget : n/a
Loop Detection : n/a
Short cable power saving : Yes
Energy Efficient Ethernet Support (IEEE 802.3az) : Yes
Jumbo Frame Support : 9KB
Queue WRR Ratio : 1:2:4:8
MAC Table Size : 8K
Packet buffer size : 512.5KB
IEEE 802.1p QoS : Yes
Max Power Consumption : 12W
Operating Temperature : 0 to 50° C
MTBF (hours) : 1,016,877 hrs
FCC Class : A
