A USB4® multi-port hub incorporates the latest USB4® controller offering compatibility with Thunderbolt™ 4 and older USB™ specifications.
With up to 40Gbps of throughput, dynamic data, and display bandwidth allocation for efficient display data flow, you can easily create a high-definition monitor setup. Enjoy up to 8K resolution and access data faster without affecting system performance. Additionally, it has four USB™ SuperSpeed+ 10Gbps ports (2 USB-C® and 2 Type-A) for charging, connecting peripherals and high-speed data storage devices. It is also equipped a USB-C® Power Delivery port to charge your laptop and power your connected devices with up to 100W of pass-through power.
- Supports resolutions up to 8K60 and 4K144
- Compatible with Thunderbolt™ 4, Thunderbolt™ 3 or other USB-C® host laptops
- Two SuperSpeed+ USB™ Type-A 10Gbps port to accommodate modern peripherals
- Two USB-C® port supports up to 10Gbps data transmission
- Power Delivery 3.0 offers up to 100W of pass-through charging
- Multiple data and display protocols efficiently share bandwidth to offer optimal performance
- Wide compatibility with various operating systems and devices
- Plug-and-play, no driver installation required
Hardware
Audio Supported
Yes
Host Connector
1 - USB4® Male
Network Interface
N/A
Ports
1- USB-C® 3.2 Gen2 10Gbps data transmission
1- USB-C® power delivery 3.0 100W with 10Gbps data transmission
2- USB™ Type-A 3.2 Gen2 10Gbps data transmission
1- 8K HDMI™
Power Source
Bus-powered or self-powered
Video Output
1 - HDMI™ Female
Warranty
2 Year Limited
Performance
Audio Channel
2.1 via HDMI™
Compatible Networks
N/A
Displays Supported
1
Max Data Transfer Rate
10Gbps
Max Display Refresh Rate
144Hz @ 1920 x 1080
144Hz @ 2560 x 1440
60 Hz @ 3840 x 2160
144 Hz @ 3840 x 2160 (* Only for DSC host)
30 Hz @ 7680 x 4320
60 Hz @ 7680 x 4320 (* Only for DSC host)
Max Display Resolution
7680 x 4320
Power
Input Current
Up to 5A
Input Voltage
Up to 20V
Output Current
Up to 4.75A
Output Voltage
Up to 20V
Power Consumption
≤ 900 mA
Power Delivery
Up to 100W via USB-C®
Physical Specifications
Cable Length
200 mm
Colour
Space Grey
Enclosure Type
Aluminum
Operating Humidity
< 85% non-condensing
Operating Temperature
-1 to 41°C
Product Depth
45 mm
Product Height
11 mm
Product Width
116.31 mm
Product Weight
74 g
Storage Humidity
< 85% non-condensing
Storage Temperature
-17 to 68°C
Package Contents
1 - JCH453 USB4® 8K60 Slim Hub
1 - Quick Installation Guide (QIG)
