Featuring all the ports you need, the 4K60 Elite USB-C® 10Gbps Travel Dock is equipped with an advanced USB-C® E-Mark chip for compatibility with USB4™, Thunderbolt™ 3, and Thunderbolt™ 4 hosts and devices.
It supports DisplayPort™ 1.4 allowing you to add a 4K 60Hz HDMI™ display and has a Gigabit Ethernet port for adding a wired network. It includes three USB™ SuperSpeed 10 Gbps ports (1 USB-C® and 2 USB™ Type-A) for peripheral connectivity or downstream charging. The USB-C® port also offers up to 100W of power pass-through when connected to a power adapter.
- Built-in advanced USB-C® E-Mark integrates USB4™, Thunderbolt™ 3 and Thunderbolt™ 4 compatibility
- Backwards compatible with USB™ 3.2/3.1
- Features a 4K HDMI™ output, supporting video resolutions up to 3840 x 2160 at 60 Hz
- Maximize your gaming experience with 1920 x 1080 @ 144 Hz refresh rate
- Extending one display up to 3840 x 2160 @ 60, easily switch to a higher refresh rate of 2560 x 1440 @ 120 Hz via HDMI™ port to enjoy your gaming under Windows® OS
- Three SuperSpeed USB™ 10Gbps downstream ports (1 USB-C® and 2 Type-A) to connect peripherals
- Charge and power connected laptop and peripherals with 100W Power Delivery
- Easily add a wired network connectivity with the Gigabit Ethernet port
- Plug-and-play, no driver installation required
Hardware Warranty: 2 Year Limited Host Connector: 1 - USB-C® Male Video Output: 1 - HDMI™ Female Power Source: Bus-powered or self-powered Network Interface: RJ45 (Gigabit Ethernet) Audio Supported: Yes Ports: • 1 - USB-C® SuperSpeed 10Gbps • 2 - USB™ Type-A SuperSpeed 10Gbps • 1 - USB-C® Power Delivery 3.0 & USB™ 5Gbps data transfer • 1 - 4K HDMI™ • 1 - SD™ & microSD™ 4.0 memory card reader/writer • 1 - RJ45 Gigabit Ethernet Performance Maximum Display Resolution: 3840 x 2160 Maximum Display Refresh Rate: 3840 x 2160 @ 60 Hz, 2560 x 1440 @ 120 Hz, 1920 x 1080 @ 144 Hz (Windows®) Maximum Data Transfer Rate: 10Gbps Displays Supported: 1 Compatible Networks: 10/100/1000Mbps Audio Channel: 2.1 via HDMI™ Power Power Delivery: Up to 100W via USB-C® Power Consumption: ≤ 400 mA Input Current: Up to 5A Input Voltage: Up to 20V Output Current: Up to 4.25A Output Voltage: Up to 20V Physical Specifications Color: Space Grey Enclosure Type: Aluminum Cable Length: 7.87 in. (200 mm) Product Height: 0.62 in. (16 mm) Product Width: 5.4 in. (138 mm) Product Depth: 1.96 in. (50 mm) Product Weight: 3.77 oz (107g) Storage Temperature: 0 to 155°F (-17 to 68°C) Storage Humidity: < 85% non-condensing Operating Temperature: 30 to 116°F (-1 to 41°C) Operating Humidity: < 85% non-condensing System Requirements • Available USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0. (Please refer to the manufacturer of your computer for more information about your device.) • The host device must support DisplayPort™ 1.4 to achieve 4K resolution at 60 Hz. Example DisplayPort™ 1.4 devices are listed as follows, but not limited to: |
- Macbook Air® 13" 2019 or later |
Package Contents
• 1 - JCD393 4K60 Elite USB-C® 10Gbps Mini Dock
• 1 - Quick Installation Guide (QIG)
