Specs
General
Dimensions
72.8×47.2×33.1 mm (L×W×H)
Weight
149 g
Waterproof
20 m without the Waterproof Case, 60 m with the Waterproof Case
Before use, close the battery compartment cover and the USB-C port cover, and tighten the Glass Lens Cover. It is recommended to install Waterproof Case for long-term underwater shooting or in environments with high water impact pressure. Osmo Action 6 and its Waterproof Case have an IP68 waterproof rating. Do not use the camera in hot springs or extreme underwater environments, or let it come into contact with corrosive or unknown liquids.
Number of Microphones
3
Touchscreens
Front Screen: 1.46-inch 331 ppi 342×342
800 cd/㎡ max brightness (typical)
Rear Screen: 2.5-inch 326 ppi 400×712
800 cd/㎡ max brightness (typical), 1000 cd/㎡ peak brightness
Supported SD Cards
microSD (up to 1 TB)
Recommended microSD Cards
Recommended Models:
Lexar Professional SILVER PLUS 64GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 128GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 256GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 512GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 1TB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 1TB U3 A2 V30 microSDXC
Camera
Sensor
1/1.1-inch CMOS
Lens
FOV: 155°
Aperture: f/2.0-f/4.0
Focus Range (at aperture f/4.0): 0.2 m to ∞
ISO Range
Photo: 100-25600
Video: 100-51200*
* ISO 51200 is available only in SuperNight mode. For all other video modes, the maximum ISO is 25600.
Electronic Shutter Speed
Photo: 1/8000-30 s
Video: 1/8000s to the limit of frames per second
Max Photo Resolution
7168×5376
Zoom
Digital Zoom
Photo: Max 2×
Video: Max 2×
Not supported in 38MP/34MP photo mode, SuperNight, Subject Tracking, Slow Motion, or Timelapse modes.
Still Photography Modes
Single: Approx. 38 MP
Countdown: Off/0.5/1/2/3/5/10 s
Burst: Up to 30 images/3 s
Video
4K Custom: 3840×3840@24/25/30/48/50/60fps
4K (4:3): 3840×2880@100/120fps
4K (4:3): 3840×2880@24/25/30/48/50/60fps
4K (16:9): 3840×2160@100/120fps
4K (16:9): 3840×2160@24/25/30/48/50/60fps
4K (9:16): 2160×3840@100/120fps
4K (9:16): 2160×3840@24/25/30/48/50/60fps
2.7K (4:3): 2688×2016@100/120fps
2.7K (4:3): 2688×2016@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@100/120fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@100/120fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@100/120/200/240fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@100/120/200/240fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
SuperNight
4K (16:9): 3840×2160@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
Subject Tracking
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
Slow Motion
4K: 4x (120fps)
2.7K: 4x (120fps)
1080p: 8x (240fps), 4x (120fps)
Hyperlapse
4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
Timelapse
4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40 s,
1/2/5/30/60 mins
Duration: 5/10/20/30 mins, 1/2/3/5 hours, ∞
Stabilization
EIS:
RockSteady 3.0
RockSteady 3.0+
HorizonBalancing
HorizonSteady
EIS is not supported in Slow Motion and Timelapse modes.
HorizonSteady and HorizonBalancing are supported for 1080p (16:9), 2.7K (16:9), 4K (16:9), and 4K Custom videos with frame rates of 60fps or below.
Pre-Rec
Pre-Recording Duration: 5/10/15/30 s, 1/2/5 mins
Max Video Bitrate
120 Mbps
Supported File System
exFAT
Photo Format
JPEG/RAW
Video Format
MP4 (HEVC)
Built-in Storage Capacity
The camera features 64 GB of built-in storage, with 50 GB available for use. The storage capacity can be expanded by inserting a microSD card.
Audio Recording
48 kHz 16-bit; AAC
Battery
Type
Li-ion 1S
Capacity
1950 mAh
Energy
7.5 Wh
Voltage
3.87 V
Operating Temperature
-20° to 45° C (-4° to 113° F)
Charging Temperature
5° to 40° C (41° to 104° F)
Operating Time
240 minutes
Measured at a room temperature of 25° C (77° F), while recording 1080p/24fps (16:9) video, with RockSteady on, Wi-Fi off, Voice Control and Gesture Control off, and screens off. Data was collected in a controlled environment and should be taken as reference only.
Connection
Wi-Fi Operating Frequency
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Protocol
Wi-Fi 6.0
802.11 a/b/g/n/ac/ax
Wi-Fi Transmitter Power (EIRP)
2.4 GHz: < 23 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: < 23 dBm (FCC/SRRC), < 14 dBm (CE)
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
< 13 dBm
Bluetooth Protocol
BLE 5.1
General
Dimensions
72.8×47.2×33.1 mm (L×W×H)
Weight
149 g
Waterproof
20 m without the Waterproof Case, 60 m with the Waterproof Case
Before use, close the battery compartment cover and the USB-C port cover, and tighten the Glass Lens Cover. It is recommended to install Waterproof Case for long-term underwater shooting or in environments with high water impact pressure. Osmo Action 6 and its Waterproof Case have an IP68 waterproof rating. Do not use the camera in hot springs or extreme underwater environments, or let it come into contact with corrosive or unknown liquids.
Number of Microphones
3
Touchscreens
Front Screen: 1.46-inch 331 ppi 342×342
800 cd/㎡ max brightness (typical)
Rear Screen: 2.5-inch 326 ppi 400×712
800 cd/㎡ max brightness (typical), 1000 cd/㎡ peak brightness
Supported SD Cards
microSD (up to 1 TB)
Recommended microSD Cards
Recommended Models:
Lexar Professional SILVER PLUS 64GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 128GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 256GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 512GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 1TB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 1TB U3 A2 V30 microSDXC
Camera
Sensor
1/1.1-inch CMOS
Lens
FOV: 155°
Aperture: f/2.0-f/4.0
Focus Range (at aperture f/4.0): 0.2 m to ∞
ISO Range
Photo: 100-25600
Video: 100-51200*
* ISO 51200 is available only in SuperNight mode. For all other video modes, the maximum ISO is 25600.
Electronic Shutter Speed
Photo: 1/8000-30 s
Video: 1/8000s to the limit of frames per second
Max Photo Resolution
7168×5376
Zoom
Digital Zoom
Photo: Max 2×
Video: Max 2×
Not supported in 38MP/34MP photo mode, SuperNight, Subject Tracking, Slow Motion, or Timelapse modes.
Still Photography Modes
Single: Approx. 38 MP
Countdown: Off/0.5/1/2/3/5/10 s
Burst: Up to 30 images/3 s
Video
4K Custom: 3840×3840@24/25/30/48/50/60fps
4K (4:3): 3840×2880@100/120fps
4K (4:3): 3840×2880@24/25/30/48/50/60fps
4K (16:9): 3840×2160@100/120fps
4K (16:9): 3840×2160@24/25/30/48/50/60fps
4K (9:16): 2160×3840@100/120fps
4K (9:16): 2160×3840@24/25/30/48/50/60fps
2.7K (4:3): 2688×2016@100/120fps
2.7K (4:3): 2688×2016@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@100/120fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@100/120fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@100/120/200/240fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@100/120/200/240fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
SuperNight
4K (16:9): 3840×2160@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
Subject Tracking
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
Slow Motion
4K: 4x (120fps)
2.7K: 4x (120fps)
1080p: 8x (240fps), 4x (120fps)
Hyperlapse
4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
Timelapse
4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40 s,
1/2/5/30/60 mins
Duration: 5/10/20/30 mins, 1/2/3/5 hours, ∞
Stabilization
EIS:
RockSteady 3.0
RockSteady 3.0+
HorizonBalancing
HorizonSteady
EIS is not supported in Slow Motion and Timelapse modes.
HorizonSteady and HorizonBalancing are supported for 1080p (16:9), 2.7K (16:9), 4K (16:9), and 4K Custom videos with frame rates of 60fps or below.
Pre-Rec
Pre-Recording Duration: 5/10/15/30 s, 1/2/5 mins
Max Video Bitrate
120 Mbps
Supported File System
exFAT
Photo Format
JPEG/RAW
Video Format
MP4 (HEVC)
Built-in Storage Capacity
The camera features 64 GB of built-in storage, with 50 GB available for use. The storage capacity can be expanded by inserting a microSD card.
Audio Recording
48 kHz 16-bit; AAC
Battery
Type
Li-ion 1S
Capacity
1950 mAh
Energy
7.5 Wh
Voltage
3.87 V
Operating Temperature
-20° to 45° C (-4° to 113° F)
Charging Temperature
5° to 40° C (41° to 104° F)
Operating Time
240 minutes
Measured at a room temperature of 25° C (77° F), while recording 1080p/24fps (16:9) video, with RockSteady on, Wi-Fi off, Voice Control and Gesture Control off, and screens off. Data was collected in a controlled environment and should be taken as reference only.
Connection
Wi-Fi Operating Frequency
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Protocol
Wi-Fi 6.0
802.11 a/b/g/n/ac/ax
Wi-Fi Transmitter Power (EIRP)
2.4 GHz: < 23 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: < 23 dBm (FCC/SRRC), < 14 dBm (CE)
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
< 13 dBm
Bluetooth Protocol
BLE 5.1
